Feature :
- Precise de-greased & pre located outer MS sheet chamber duly powder coated & painted.
- Better mineral / glasswool insulation keeps the surface Temperature normal & avoid heat / steam loss.
- Unique design of Radial locking for minimum steam loss, assure accurate steam generation / sterilization.
- S. Steel 304 grade argon welded Cylindrical inner Tank / Vessel having S. Steel tubular immersion heater for steam generation
- Lid is made of Thick mild S.S. Lined for double protection
Optional: All S. Steel Thick Lined Lid/ S.S. Ring 304 grade
(All S.S. Outer Body -304 grade Steel On Customer request.)
- Fitted with Painted mild steel Ring & Radial locking duly chrome plated.
- Paddle lifting device is also provided.
- Lid is having built in safety valve, Release Valve Pressure gauge, water level/indicator
- Supplied with S. Steel cylindrical basket.
- Pressure range is adjustable form 5PSI-20PSI ± 3PSI or better.
Optional:
- Automatic low water Cut off Device / with Alarm
- Timer 0-60 minute
- Digital Indicator / Digital Timer 0-999 Min / Hrs.
- RS-232/ Touch Screen PLC Controller
Applications
Useful for hospital Research, Pharmaceutical, Bio Tech Laboratory.
Specification
| Models | UTS 1.26 | UTS 1.26A | UTS 1.26B | UTS 1.26C | UTS 1.26D |
| Interior (mm) | 450x250mm | 500x300mm | 550x350mm | 600x450mm | 750x550mm |
| Heater “W” | 2 KW. | 2 KW. | 3 KW. | 4 KW. | 5/6KW. |
| Basket | 1 No. | 1 No. | 1 No. | 1 No. | 1 No. |
Technical Parameters
Pressure Range | : 5-20PSI± 3PSI |
Temperature Range | : 120°c appox. At 15-20PSI appox. |
Power Consumption | : 220/230V AC ± 10% Single Phase 50Hz |
Control Panel | : Temp./ Pressure Indicator, Pressure Switch, |
PS: | : Also available in Horizontal model (Sizes as mentioned above) |
