Feature :
- Precise, Hot Air Drying
- Better Mineral/Blanket Insulation for high Temperature & to avoid heat loss
- silent Hot Air Bloer, unique design of Air Circulation provide through out uniform Air movement
- Unique design of ventilation keeps the surface of the instruments from being Burnt even when the instrument i.e. Oven Temperature maintained at 200°C
- Polish / Hair Line 304 grade S. Steel sheet interior, long operation, corrosion resistant
- Kanthal A-1 Super quality coil shaped & Air heater tubular model wound on side / on the back of the Oven for better accuracy
- Full feature with Digital Temperature Controller cum indicator having alarm facility (On Customer request)
- Toughened Glass view window to observe / Test the material without disturbing the Temperature condition of the chamber.
- Working Temperature required as per IS: ASTM is 163°C ± 1°C
- Provide with detachable metal shaft (Both for loss on heating / Thin Film Oven)
- Reduction gear is fitted from outside rotated by a vertical shaft having 5-6 RPM
Applications
For Bitumen Testing Loss of weight, Softening Paint, Penetration Loss of wt in Bitumen & Flux Oils (For Construction/Road Projects Department/ Industries.)
Specification:
| Models | UTS 1.44 THIN FILM OVEN | UTS 1.44A LOSS ON HEATING OVEN |
| Capacity Liters | 60 Liters | 60 Liters |
| Interior (mm) | 400 x 400 x 400mm | 400 x 400 x 400mm |
| 16″ x 16″ x 16″ | 16″ x 16″ x 16″ | |
| Heater Wattage | 1.5 KW. | 1.5 KW. |
| No. Of Plate Rotating | One (1 No.) | One (1 No.) |
| Dimension are expressed in (Length x Depth x Height) | ||
Technical Parameters:
Control Panel: Mains & Load Indicator Fine Temperature Controller, Digital Temperature Controller, Fan Switch, Rotating Motor, Control Switch
Temperature Stability: ±1°C or better
Housing Material: CRC/MS sheet duly painted
Duty Cycle: Continuous
Optional: RS-232/Touch Screen PLC Controller
