- Better low speed stirring with even small liquid volume.
- Better quality motor for higher Torque at low speeds.
- Stirring accomplished by small teflon coated magnetic paddle.
- Paddle size as per magnetic stirrer cap. Requirement.
- Accurate speed control & temperature control.
- S. Steel 304 grade Top housing.
- Better quality Kanthal heaters all fire proof wiring connection better durability.
- Designed to reduce the fumes entrance in the unit.
Applications
For Medical, Research Institute, Bio–Tech Pharmaceutical Agriculture, Food Industries.
Specification
Models | UTS 1.20 | UTS 1.20A | UTS 1.20B |
Capacity (Litre) | 1 Litre | 3 Litre | 35Litre |
Heater Wattage “W” | 150W | 300W | 500W |
Dimension (Apox.) | 160x200x160 | 160x200x160 | 175x225x185 |
Dimensions are expressed in Length x Height x Depth
Technical Parameters
Control Panel: Speed Regulator, Temp. Indicator & mains.
Housing Material: CRC/MS sheet duly powder coated.
Optional
All S. Steel body having S. Steel Top magnetic Stirrer without
hot plate having different dimension.
Digital RPM & Temp.( Price on Request)
Duty Cycle: Continuous
Power Consumption: 220/230V AC 50HZ single phase.
