- Precise Hot Air Drying Oven & sterilization better mineral/ceramic wool Insulation to avoid
- Low Noise Blower, unique design of Air Circulation provide throughout the chamber.
- Unique design of ventilation keeps the surface of the Instruments i.e oven/Drier Temp.Maintained at 200/250°C
- Polish S. Steel sheet 304 grade 22 ‘SWG’ thick interior, corrosion resistant long life operation having adjustableSS shelves to make space for difference height
- Kanthal A-1 Superior quality Industiral heater fitted on the sides & at the back of the drier / Oven (as per size & customer requirement)
- Full features Digital Temp. Controller Cum Indicator & Microprocessor Based PID Temp. Controller Cum Indicator.
Optional: Digital Timer 0-99 Hrs. Inner M.S Sheet/GI Sheet Chamber Instead Of SS 304Grade Sheet
Applications
Drying, Paint, Bitumen & Rubber Industries, Medical & Food Industries, Institute, Agriculture requiring Controlled Temp. Above Ambient.
specification
| Models | UTS:1.01 Single Door | UTS:1.01A Single Door | UTS:1.01B Double Door |
| Interior(mm)Alum/SS | 900x900x900 | 900x900x1200 | 1200x1200x1200 |
| Heater Wattage”W” | 4.0KW | 4.5KW | 4.5/5.0KW |
| Shelves | 2/3 | 3 | 3 |
Dimensions are expressed in Length x Depth x Height
Technical Parameters
Temperature Range: Ambient to 250°C Controlled from 50°C – 250°C.
Temperature Stability: ±1°C or better In Microprocessor Based PID Temp. Controller model ± 0.5°C.
Housing Material: RC /Mild Steel Heavy Duty Having Angle Iron Frame at the bottom with Castor wheel duly painted/powder coated.
