Applications & Key Features:
- Designed for digestion of COD test samples and multi-function dry bath heating.
- Precise temperature control from ambient ±5°C to 150°C with+1°C accuracy.
- User’s sell compensation functions for temperature to counter for difference between block temperature and sample temperature
- Fitted with MICROPROCESSOR BASED PID TEMPERATURE INDICATOR-cum-CONTROLLER for auto control with respect to time and temperature and is also fitted with IN-BUILT BUZER TIMER for AUTO TIME CONTROL to indicate cycle end.
- Microprocessor Based PID Temperature Indicator cum-Controller having individual display for set value and process value.
- Recessed well/ cavity accommodates aluminum insert block.
- Samples after being digested for 2 hours can be analyzed using calorimeter or conventional titration method.
- COD Digester Is The Most Accepted Thermoreactor For Determination of Chemical Oxygen Demand in Various Substances. Chemical Oxygen Demand (COD) is a measure of the capacity of water to Consume Oxygen during the decomposition of Organic Matter and the Oxidation of inorganic chemicals such as Ammonia and Nitrite. COD Measurements are commonlymade on samples of waste water or of Natural waters contaminated by domestic or industrial wastes. Chemical Oxygen Demand is measured as a standardized laboratory assay in which a closed water sample is incubated with a Strong Chemical Oxidant under specific conditions of temperature and for a particular period of time
- High performance and user friendly controls combine to produce a specification which offers exceptional efficiency and reliability. The benefit to you-convenient, no fuss heating!
- Excellent temperature control. By PID
- Uniform and stable heating throughout the heating Block
- Compact in size
Technical Specification:
| UTS 1.67 | COD Digester |
| Controller | Microprocessor Based PID Temperature Indicator cum-Controller with an in built digital timer and alarm. |
| Display | LED with set value (SV) and Process Value(PV) |
| Heater Load | 450/750 W (Approx.) |
| Tube Cavity | 40mm(0)x 65mm(D) Approx. |
| No. of Cavities | 15 Holes to accommodate 15 samples |
| Glass Tube Size | Supplied with 15 nos. of glass tubes of size 38mm (0x200 mm (Length) |
| Glass Air Condenser | Size Supplied with 15 nos. of air condensers of 600 mlength each |
| Sample Size | 20 ml |
| Temperature Range | Ambient ±5°C to 150°C |
| Temperature Accuracy | +1°C |
| Sensor | RTD (PT-100) |
| Material External | Powder Coated MS CRC Sheet |
| Block | Polished Aluminium |
| Tube Rack | I No. |
| Timer | Fitted with AUTOMATIC DIGITAL MINUTE TIMER which starts automatically when set/desired value of temperature is achieved. When the set time period is over the heaters get switched off automatically |
| Buzzer | Alarm for cycle end |
| Power | Supply 220/230 V AC Supply |
